The Beat-Sonic CS11A is a front camera interface designed for select 2014-2025 Lexus models with factory display screens. This interface allows you to add a front camera to your factory Lexus screen while working together with your factory backup camera.
Front camera is not included and must be purchased separately. This product is the interface module only.
The CS11A allows you to switch between the front camera, rear camera, and factory Lexus screen using the included selector button. It is ideal for front parking, avoiding curbs, avoiding front obstacles, and assisting vehicles with front spoilers or lowered suspension.
Why choose the CS11A front camera interface?
Adding a front camera to a compatible Lexus factory screen requires the correct interface. The CS11A provides a plug-and-play solution that integrates a front camera into the factory display without splicing or modifying the factory harness.
By pressing the selector button, the front camera is displayed for a preset amount of time using the built-in programmable timer. The timer can be set to 5 seconds, 10 seconds, 15 seconds, 20 seconds, or timer disabled for push-on / push-off operation.
The CS11A also allows the rear camera to be displayed without shifting the vehicle into reverse, giving you more control over front and rear camera visibility when parking or maneuvering in tight spaces.
Key features
- Adds front camera connectivity to select Lexus factory screens
- Switch between front camera, rear camera, and factory Lexus screen
- Ability to display rear camera without shifting into reverse
- Seamless operation with the press of a button
- Built-in programmable timer: 5 sec, 10 sec, 15 sec, 20 sec, or timer disabled
- Control button to manually turn on the front camera
- Built-in video noise filter for high-definition resolution
- Built-in image stabilization and noise filter for excellent image quality
- Switch blank adapter accommodates 3 different factory switch blank sizes
- Plug-and-play installation with no modification or splicing to the factory harness
- Works together with the factory backup camera
- Made in Japan
Recommended front cameras
Front camera is sold separately. The following Beat-Sonic front cameras are recommended:
- BCAM10AW - white front license plate mounting-type camera
- BCAM11B - black front grille mounting-type camera
- BCAM13 - black front flat mounting-type camera
Compatible vehicles
The CS11A is compatible with the following Lexus vehicles:
- 2014-2017 Lexus CT 200h
- 2015-2022 Lexus ES 350 / ES 300h
- 2015-2020 Lexus GS 200t / GS 300 / GS 350 / GS 450h / GS F
- 2014-2023 Lexus GX 460 without 360 / Bird's Eye View Camera only
- 2014-2025 Lexus IS 200t / IS 250 / IS 300 / IS 350
- 2018-2023 Lexus LC 500 / LC 500h
- 2015-2017 Lexus LS 460 / LS 600h with factory navigation only
- 2015-2021 Lexus NX 200t / NX 300 / NX 300h without Intelligent Clearance Sonar or Intuitive Parking Assist
- 2015-2025 Lexus RC 200t / RC 300 / RC 350 / RC F
- 2016-2022 Lexus RX 350 / RX 450h without 360 camera only
- 2019-2022 Lexus UX 250 / UX 200 without Parking Support and/or Parking Support Brake systems
Not sure if this fits your Lexus? Email info@beatsonicusa.com with your year, model, trim, and factory camera/parking assist system before purchasing.
Important compatibility notes
- Front camera is sold separately
- GX 460 compatibility is for models without 360 / Bird's Eye View Camera only
- RX compatibility is for models without 360 camera only
- NX compatibility excludes models with Intelligent Clearance Sonar or Intuitive Parking Assist
- UX compatibility excludes models with Parking Support and/or Parking Support Brake systems
Switch blank adapter
The included switch blank adapter accommodates 3 different factory switch blank sizes for a clean installation. If no suitable switch blank is available, the selector button can be surface mounted using the pre-applied double-sided tape. The switch blank adapters are not required when surface mounting the selector button.
Specifications
- Voltage: DC11V-15V
- Current consumption: 50mA or less
- External dimensions: 40mm x 25mm x 57mm
- Weight: 55g
