The Beat-Sonic EAZ-C02 is a plug-and-play power harness that lets you power a new active subwoofer directly from your Toyota or Lexus power seat connector — no firewall routing, no running wire to the battery terminal, and no permanent modifications to your vehicle. Clean, simple, and fully reversible.
Professional local installation available in La Mirada, Southern California. Contact us at info@beatsonicusa.com to book.
Why this harness makes adding a subwoofer so much easier
Traditionally, powering an aftermarket subwoofer meant routing a power cable from the battery through the firewall — a time-consuming process that risks damage to factory wiring and requires drilling or finding existing grommets. The EAZ-C02 eliminates all of that. It taps into the existing power seat connector under your seat, which already carries a clean 12V power supply, and provides a fused, plug-and-play power connection for your active subwoofer or amplifier right where you need it.
Key features
- No firewall routing required — powers your subwoofer directly from the factory power seat connector
- Plug-and-play installation — OEM-grade connectors, no cutting, no modifications
- Compatible with active subwoofers and amplifiers with high-level inputs
- 20A ATO blade-type fuse included — protects your vehicle's electrical system
- 16 AWG wire for 12V battery and ground connections
- 800mm (31-inch) cable length from T-harness — plenty of reach for under-seat subwoofer placement
- Maximum continuous power: 280W at 14V
- High-quality OEM-grade connectors for a secure, reliable connection
What's included
- 1 x EAZ-C02 wiring harness set
General specifications
- Wire gauge: 16 AWG (12V battery and ground)
- Cable length from T-harness: approx. 800mm (31 inches)
- Fuse: 20A ATO blade-type
- Maximum continuous power: 280W at 14V
Compatible vehicles
The EAZ-C02 is compatible with the following Toyota and Lexus models equipped with power seats:
Toyota models with power seats
- 2013–2025 Toyota 4Runner
- 2013–2022 Toyota Avalon
- 2015–2025 Toyota Camry
- 2014–2025 Toyota Corolla (driver's side only)
- 2022–2025 Toyota Corolla Cross (driver's side only)
- 2023–2025 Toyota Corolla Hatchback (driver's side only)
- 2018–2025 Toyota C-HR (driver's side only)
- 2023–2025 Toyota Crown
- 2025 Toyota Crown Signia
- 2023–2025 Toyota GR Corolla (driver's side only)
- 2020–2025 Toyota Highlander including HV
- 2024–2025 Toyota Grand Highlander
- 2018–2025 Toyota Hilux (driver's side only)
- 2024–2025 Toyota Land Cruiser 250 / Prado
- 2015–2022 Toyota Land Cruiser Prado
- 2016–2025 Toyota Mirai
- 2016–2025 Toyota Prius (driver's side only)
- 2017–2025 Toyota Prius Prime (driver's side only)
- 2016–2025 Toyota RAV4
- 2023–2025 Toyota Sequoia HV
- 2021–2025 Toyota Sienna HV
- 2020–2025 Toyota Tacoma
- 2014–2025 Toyota Tundra
- 2021–2025 Toyota Venza
Lexus models
- 2015–2017 Lexus CT 200h
- 2007–2025 Lexus ES 250 / ES 300h / ES 350
- 2016–2020 Lexus GS-F
- 2010–2023 Lexus GX 460
- 2024–2025 Lexus GX 550
- 2014–2025 Lexus IS 300 / IS 350 / IS 500
- 2018–2025 Lexus LC 500 / LC 500C
- 2022–2025 Lexus LX 600
- 2018–2025 Lexus NX 250 / NX 300 / NX 300h / NX 350 / NX 350h / NX 450h+
- 2015–2025 Lexus RC 200t / RC 300 / RC 350 / RC-F
- 2023–2025 Lexus RX 350 / RX 350h / RX 450h / RX 500h
- 2023–2025 Lexus RZ 300E / RZ 450h
- 2024–2025 Lexus TX 350 / TX 500h / TX 500h+
- 2019–2025 Lexus UX 200 / UX 250h / UX 300h
Note: Several Toyota models are driver's side only — see individual model notes above. Not sure if this fits your specific vehicle? Email info@beatsonicusa.com with your year, model, and trim before purchasing.
Frequently asked questions
Do I still need to run a wire to the battery?
No. The EAZ-C02 taps into your factory power seat connector, which already carries a 12V power supply. No firewall routing and no battery terminal connection required.
What type of subwoofer is this compatible with?
The EAZ-C02 is compatible with active (powered) subwoofers and amplifiers with high-level inputs. Maximum continuous power supported is 280W at 14V.
My Toyota model says driver's side only — what does that mean?
On those models, the power seat connector on the driver's side is compatible with this harness but the passenger side is not. The harness will work for powering a subwoofer placed under or near the driver's seat.
Is this fully reversible?
Yes. The EAZ-C02 uses OEM-grade plug-and-play connectors. It can be removed at any time with no permanent changes to your vehicle.
Does this ship to Canada or internationally?
Yes. We ship to Canada and Mexico.
